Product Description
Technical Spec :
Heatsink Specifications:
Dimension：L94 mm x W94 mm x H110 mm
Heat pipes：6 mm heatpipe x 4 units
Copper Base：C1100 Pure copper nickel plated
TL-P9 FAN Spec：
Dimension：L92 mm x W92 mm x H25 mm
Weight：110g
Rated Speed：2200 RPM±10% (MAX)
Noise Level：23.85 dBA
Air Flow：32.77 CFM (MAX)
Air Pressure：1.98 mm H2O (MAX)
Ampere：0.10 A
Connector：4 Pin (PWM Fan connector)
Bearing Type : S-FDB Bearing
Click to download Installation Guide
Click to download Product Images
